Film Stocks
Print, Negative, Interpositive, Internegative.
Mono and Color.
The Cintel Scanner is a complete solution to realtime film scanning and grading that features precision mechanical film handling components, optics, a high intensity diffuse light source and a built in camera. The precision capstans handle film more gently than ever before. Cintel Scanner includes a 35mm film gate, film spools, a set of four cleaning rollers, desk mount feet and DaVinci Resolve Studio software. Cintel transfers film directly to DaVinci Resolve which gives you the power to edit film rolls back together, scans to be color graded, reframed, noise reduced and audio extracted. Using DaVinci Resolve to operate the scanner means you have much more creative control than a simple telecine because DaVinci Resolve has many more features than is possible to do in hardware.
Print, Negative, Interpositive, Internegative.
Mono and Color.
35mm (2, 3, 4 perforations),
Super 35mm (2, 3, 4 perforations).
16mm, Super 16mm
4096 x 3072
3840 x 2880 - Super 35
3390 x 2864 - Standard 35
3390 x 2465 - Anamorphic 35
1903 x 1143 - Super 16
1581 x 1154 - Standard 16
3840 x 2160 Ultra HD
1920 x 1080 HD
(auto selected to match monitor resolution)
Normal Scans: 12 stops
HDR Scans: up to 3.5 additional stops
Extraction from scanned image.
Rubber Capstan.
Diffuse light source. Cleaning rollers.
Desk Mount. Wall Mount.
Run speed:
1 - 30 fps
Shuttle:
1 - 100 fps (35mm)
1 - 200 fps (16mm)
5 - 30 fps/s
Up to 2% guaranteed, more may be possible if user care is taken.
2000 ft (35mm)
1 x HDMI 1.4 10-bit 4:2:2 for preview purposes only.
Thunderbolt™ 3 for capture of image and audio, software updates and supports USB-C charging with 15W at 5V.
PCI Express 4 lane generation 2.
XLR3 Bi-phase: 4.5 Volt DC coupled.
Timecode: 1.5 Volt DC coupled with support for 24, 25 and 30 fps.
2 Channels of professional balanced analog audio with sample rate converter via XLR connectors with 10dBV levels.
1 Channel with sample rate converter on XLR connector.
XLR6
Cintel requires Desktop Video installed on the host computer to operate. Scanning can be controlled though DaVinci Resolve or through third party software using the Cintel SDK.
Operating Systems as per Desktop Video Read Me
Mac 11.1 Big Sur,
Mac 12.0 Monterey or later.
Windows 10, 64-bit.
Windows 11.
Linux
Cintel Scanner 16mm Gate HDR
Cintel Audio and KeyKode Reader
Cintel Scanner 35mm Gate HDR
Cintel Cleaning Roller Kit
Blackmagic PCI Express Cable Kit
100 - 240V AC.
200W
18 to 28°C (64.4º to 82.4º F).
Maximum 65% non-condensing.
Cintel Scanner G3 HDR+
Desk Stand
8 x 1mm Reel Spacers
Cintel Scanner 35mm Gate
DaVinci Resolve Studio Dongle
Welcome wallet with QR code for software download
12 Month Limited Manufacturer's Warranty
